The Cisco Firepower 2100 series security appliance includes the Firepower 2110, 2120, 2130, and 2140.
Firepower 2110/2120 and Firepower 2130/2140
View and Download Cisco Firepower 2100 Series hardware installation manual online. Firepower 2100 Series security system pdf manual download. Also for: Firepower 2110, Firepower 2120, Firepower 2130, Firepower 2140. Cisco Firepower 2100 Series Hardware Installation Guide. PDF - Complete Book (7.5 MB) View with Adobe Reader on a variety of devices. FPR2130-NGFW-K9 Cisco Firewall: NetworkTigers offers this Firewall. This Cisco FPR2130-NGFW-K9 Firewall we market is tech tested. We can overnight this Cisco FPR2130-NGFW-K9 Firewall to your site.Cisco FPR2130-NGFW-K9 - Cisco Firepower 2130 NGFW Appliance, 1RU, 1 x Network Module Bays. はじめに 本ドキュメントでは Firepower Device Manager (FDM) で管理している Firepower2100 シリーズに機器交換が発生した際に、FTD の各設定のバックアップ、及び Restore 手順について紹介します。本ドキュメントは、Firepower 2140の FXOSバージョン 2.3 (1.84)、及び FTD ソフトウェアバージョン 6.2.1 を用いて. View and Download Cisco Firepower 2100 Series hardware installation manual online. Firepower 2100 Series security system pdf manual download. Also for: Firepower 2110, Firepower 2120, Firepower 2130, Firepower 2140.
Cisco Firepower 2100 Series Features
The following table lists the features for the Firepower 2100 series.
Compare Features of Firepower 2110, 2120, 2130, and 2140
| Feature | 2110 | 2120 | 2130 | 2140 |
| Form factor | 1 RU (fits standard 19-in. (48.3-cm) square-hole rack) | |||
| Rack mountable | Yes 2 two-post mount brackets (Optional) 4-post EIA-310-D rack | Yes 4-post EIA-310-D rack (Optional) 2-two-post mount brackets | ||
| Airflow | Front to rear (cold aisle to hot aisle) | |||
| Intel x86 processor | Single 4-core at 1.8G | Single 6-core at 1.9G | Single 8-core at 2.0G | Single 16-core at 1.3G |
| Intel x86 memory | 16 GB | 32 GB | 64 GB | |
| Cavium Network Processor Unit (NPU) | Single 6-core at 1.2G | Single 8-core at 1.2G | Single 12-core at 1.2G | Single 16-core at 1.8G |
| Cavium NPU RAM | 8G | 16G | ||
| Flash | 8G (nominal) | |||
| Maximum number of interfaces | 16 | 24 | ||
| Management port | 1 Gigabit Ethernet (10M/100M/1G Base-T) | |||
| Console port | RJ-45 serial port | |||
| USB port | Type A 2.0 (500mA) | |||
| Network ports | 12 fixed RJ-45 1G/100M/10M ports (named Ethernet 1/1 through 1/12 ) | |||
| Small Form-Factor Pluggable (SFP) ports | 4 fixed 1G SFP ports | 4 fixed 1G/10G SFP+ ports | ||
| Pullout label card | Yes (displays serial number) | |||
| Grounding lug | Yes | |||
| Locator beacon | Yes | |||
| Power switch | Yes | |||
| Network modules | No | 1 network module slot Not hot swappable | ||
| AC power supply | 1 fixed AC power supply module | 2 power supply slots Ships with one 400W AC power supply Hot swappable | 2 power supply slots Ships with two 400W AC power supplies Hot swappable | |
| DC power supply | No | Yes (optional) | ||
| Redundant power | No | Yes | ||
| Fan | 4 fixed fans | 1 hot-swappable fan tray with 4 fans | ||
| Storage | 2 SSD slots (100GB ) Ships with one 100GB SSD installed in slot 1. The second slot is reserved for the MSP SSD. | 2 SSD slots (200GB ) Ships with one 200GB SSD installed in slot 1. The second slot is reserved for the MSP SSD. | ||
| Malware Storage Pack (MSP) | Yes (installed in SSD slot 2) | |||
Cisco Firepower 2100 Series-Deployment Options
You can deploy the Firepower 2100 in the following ways:
- As a firewall:
- At the enterprise Internet edge deployed in a high availability configuration
- At branch offices in either an HA pair or standalone
- As a device that provides additional application control, URL filtering, or IPS/threat-centric capabilities:
- Behind an enterprise Internet edge firewall in an inline in a transparent bump-in-the-wire configuration or as a standalone (requires hardware fail open network module support)
- Deployed passively off a SPAN port on a switch or a tap on a network, or standalone
- As a VPN device:
- For remote access VPN
- For site-to-site VPN
Supported SFP/SFP+ Transceivers
First of all you should take note of the following warnings:
- Warning: Statement 1053—Class 1M Laser Radiation; Class 1M laser radiation when open. Do not view directly with optical instruments.
- Warning: Statement 1055—Class I and Class 1M Laser; Class I (CDRH) and Class 1M (IEC) laser products.
- Warning: Statement 1056—Unterminated Fiber Cable
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do not view directly with optical instruments. Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of 100 mm may pose an eye hazard.
- Warning: Statement 1057—Hazardous Radiation Exposure
Use of controls or adjustments or performance of procedures other than those specified may result in hazardous radiation exposure.
The SFP/SFP+ transceiver is a bidirectional device with a transmitter and receiver in the same physical package. It is a hot-swappable optical or electrical (copper) interface that plugs into the SFP/SFP+ ports on the fixed ports and the network module ports, and provides Ethernet connectivity.
SFP
| 1 | Dust plug | 2 | Bail clasp |
| 3 | Receive optical bore | 4 | Transmit optical bore |
- Warning:Use appropriate ESD procedures when inserting the transceiver. Avoid touching the contacts at the rear, and keep the contacts and ports free of dust and dirt. Keep unused transceivers in the ESD packing that they were shipped in.
- Note:The 1G transceivers are limited to 1GB operation only (no auto-negotiation support). 100M/10M modes are not supported.
- Caution:Although non-Cisco SFPs are allowed, we do not recommend using them because they have not been tested and validated by Cisco. Cisco TAC may refuse support for any interoperability problems that result from using an untested third-party SFP transceiver.
Supported SFPs
The following table lists the supported transceivers.
Cisco Firepower 2100 Series User Manual Free
Optics Type | PID | Ports Supported |
SFP 1G | ||
| 1G-SX | GLC-SX-MMD | Ports 13 through 16 Ports 1 though 8 of the 8X10G network module (available only on the 2130 and 2140) |
| 1G-LH | GLC-LH-SMD | |
| 1G-EX | GLC-EX-SMD | |
| 1G-ZX | GLC-ZX-SMD | |
| 1G 1000Base-T | GLC-T | |
| 1G 1000Base-T | GLC-TE | |
SFP+ 10G | ||
| 10G-SR | SFP-10G-SR | Ports 13 through 16 Ports 1 though 8 of the 8X10G network module (available only on the 2130 and 2140) |
| 10G-LR | SFP-10G-LR | |
| 10G-LRM | SFP-10G-LRM | |
| 10G-ER | SFP-10G-ER | |
| 10G-SR-S | SFP-10G-SR-S | |
| 10G-LR-S | SFP-10G-LR-S | |
| 10G-ZR-S | SFP-10G-ZR-S | |
| 10G-ER-S | SFP-10G-ER-S | |
| H10GB-CU 1M, 1.5M, 2M, 2.5M, 3M, 5M | SFP-H10GB-CU1M SFP-H10GB-CU1-5M SFP-H10GB-CU2M SFP-H10GB-CU2-5 SFP-H10GB-CU3M SFP-H10GB-CU5M | |
| H10GB-ACU 7M, 10M | SFP-H10GB-ACU7M SFP-H10GB-ACU10M | |
| 10G-AOC 1M, 2M, 3M, 5M, 7M, 10M | SFP-10G-AOC1M SFP-10G-AOC2M SFP-10G-AOC3M SFP-10G-AOC5M SFP-10G-AOC7M SFP-10G-AOC10M | |
Cisco Firepower 2100 Series User Manual Download
Get the Best Prices on Cisco SFP GLC Modules
Hardware Specifications for the Firepower 2100 series
The following table contains hardware specifications for the Firepower 2100 series security appliance.
Specification | 2110 | 2120 | 2130 | 2140 | ||||
Physical | ||||||||
| Form factor | 1 RU (fits standard 19-in. (48.3-cm) square-hole rack) | |||||||
| Rack mountable | Yes Fixed 2-post mount brackets included Optional: 4-post EIA-310-D mount rails | Yes 4-post EIA-31-D mount rails included Optional: 2-post mount brackets | ||||||
| Dimensions (H x W x D) | 1.73 x 16.90 x 19.76 in. (4.4 x 42.9 x 50.2 cm) | |||||||
| Weight | 16.1 lb (7.3 kg) | 19.4 lb (8.79 kg) | 21 lb (9.52 kg) | |||||
Storage | ||||||||
| SSD | 100 GB
| 200 GB
| ||||||
| MSP | 800 GB
| |||||||
Memory | ||||||||
| DDR4 DRAM | 16 GB | 16 GB | 32 GB | 64 GB | ||||
Power | ||||||||
| System power | 100/240VAC 1.9A (at 100VAC), 50 to 60 Hz
| 100/240VAC 2.9A (at 100VAC), 50 to 60 Hz
| ||||||
| Power supply module | AC | AC or DC | ||||||
| Redundant power supply | No | Yes | ||||||
| Environmental | ||||||||
| Temperature | Operating: 32⁰ to 104⁰F (0 to 40⁰C) Nonoperating: -40 to 149°F (-40 to 65°C) maximum altitude is 40,000 ft | |||||||
| NEBS | Operating altitude: 0 to 13,000 ft (3962 m) Operating temperature:
| |||||||
| Humidity | Operating: 10 to 85 percent noncondensing Nonoperating: 5 to 95 percent noncondensing | |||||||
| Altitude | Operating: 10,000 ft maximum Nonoperating: 40,000 ft maximum | |||||||
| Acoustic Noise | ||||||||
| Sound pressure | 47.3 dBA (typical) 73.4 dBA (maximum) | 55.7 dBA (typical) 76.7 dBA (maximum) | ||||||
| Sound power | 60.2 (typical) 85.1 (maximum) | 66 (typical) 84.5 (maximum) | ||||||
| Air flow | Front to back | |||||||
| System Cooling Requirements | ||||||||
